Model | KEPUNI-1000 | KEPUNI-1500 |
---|---|---|
Rated output power | 1000W | 1500W |
Power regulation range | 10%-100% | 10%-100% |
Output method | Continuous/Pulse | Continuous/Pulse |
Maximum modulation frequency | 20kHz | 20-50kHz |
Power instability | ≤2% | ≤2% |
Fiber optic output interface | QBH | QBH |
Fiber length | 10m | 10m |
Fiber optic core | 14um | 25um |
Welding gun type | Left and right swing mirror welding joint | |
Whole machine power | <6kw | <7kw |
Wire feeding diameter | 0.8, 1.0, 1.2, 1.6 | |
Weight gun weight | 0.7kg | |
Size(mm) | 510*353*340 | |
Product weight | 105kg | 115kg |
Working environment temperature | 10~40℃ | |
Working environment humidity | <70% | |
Working voltage | Single-phase 220VAC±50HZ |
